Product parameters
| Item | P8 |
| Pixel Pitch | 8mm |
| Pixel Configuration | 1R1G3B |
| LED Encapsulation | SMD3535 |
| Pixel Density | 15625dost/㎡ |
| Module Resoulution | 32*16(W*H) |
| Module Size | 256mm*128mm(W*H) |
| Drive Mode | 1/4 Scan |
| Cabinet Resolution | 128*96（W*H） |
| Cabinet Size（W*H） | 1024mm*768mm |
| Cabinet Weight | 50±0.5kg |
| Brightness | ≥6000CD/㎡ |
| Drive Mode | 1/4 Scan |
| Max Power Consumption | 800W/㎡ |
| Average Power Consumption | 300W/㎡ |
| Best Viewing Angle | H:150°V:120° |
| Display Mode | Max1024*768/1280*1024 |
| Refresh Rate | ≥1200Hz |
| Best Viewing Distance | ≥8m |
| Protection Level | IP65 |
| Operating Voltage | AC220V/110V |
| Working Temperature | -20℃/+50℃ |
| Operating Humidity | -20-60/10%-85% |
