Product parameters
|
Project |
P3 |
|
Pixel spacing |
3mm |
|
Pixel composition |
1R1G1B |
|
LED encapsulation mode |
SMD2121 |
|
Pixel density |
4096dot/㎡ |
|
Module resolution |
64*64(W*H) |
|
Module size |
250mm*300mm(W*H) |
|
Scanning mode |
1/16Scan |
|
Brightness |
≥1200CD/m² |
|
Color temperature |
3200-9300K/Adjustaable |
|
Module weight |
180g |
|
Average power consumption |
10W/㎡ |
|
Angle of view |
H:160°V:160° |
|
Refresh frequency |
≥1920Hz |
|
Gray scale |
16bit |
| Optimum sight distance | ≥3mm |
|
Protection level |
IP31 |
|
Maintenance mode |
Front maintenance |
|
Working voltage |
5V |
|
Working temperature |
-20℃/+50℃ |
|
Working humidity |
10%-85% |
|
Typical life value |
100000H |
|
Software |
Windows XP ,WIN7/8/10 |
|
Application |
Circular / curved / heterosexual screen |
